Product Description

Quarternary Low Pressure Pump  Qty:1 set

◆ Flow rate range: 0.001-10.000mL/min, in 0.001mL increments

◆ Flow accuracy: ≤±0.2%(1.00ml/min, H2O,R.T.,8.5MPa)

◆ Flow precision: RSD≤0.06% (1.00ml/min, H2O,R.T.,8.5MPa)

◆ Maximum pressure: 630bar

◆ Pressure accuracy: ≤±3.0%

◆ Pressure pulsation: ≤0.2MPa

◆ Composition rang: 0-100%

◆ Composition precision: ≤0.3%RSD

◆ Composition accuracy: ≤±1.0%

Diode Array Detector (1024 photodiodes)  Qty:1set

◆ Wavelength range: 190-800nm

◆ Wavelength repeatability: ±0.1nm

◆ Wavelength accuracy: ±1nm

◆ Linearity: ≥2.0AU

◆ Baseline noise: ≤±1.0×10-5AU(empty cell, 254nm, 1.0s)

◆ Drift: ≤2.0×10-4AU/h(empty cell, 254nm, 60min)

◆ Path length: 10mm(analytical cell)

◆ Light source: Deuterium Lamp and Tungsten Lamp

System Manager   Qty:1set

◆ Integrated vacuum degasser, 4 channel

Cromsoft Chromatographic Data-processing Workstation   Qty:1set

◆ Sequence tables for any set of samples

◆ Internal and external standard calculation methods

◆ Automatically displays, prints, exports and starts other programs after the completion of a measurement.

◆ Comply with the requirements of the 21 CFR Part 11 directive of the FDA

System Kits    Qty:1set

◆ Containing required tubing, fittings, wrenches and cables for system.

◆ 7725i 6 injection valve  1 set

◆ C18 column 5μm ID4.6×200mm *1

◆ Solvent bottle 1000mL *4 set

Colunm Oven   Qty:1set

◆ Column capacity: Three columns, up to 10mm internal diameter, up to 300mm length

◆ Temperature range: Ambient+5.0 to 85℃, settable in 0.1℃ increments

◆ Temperature accuracy: ≤±0.1℃

◆ Temperature stability: ≤±0.1℃

Autosampler     Qty:1set

◆ Inject volum range: 0-100μL(standard)

◆ Precision: RSD<0.2%

◆ linearity: >0.999

◆ Sample residual: <0.005%

◆ Number of sample plates: Two of 60 position 2-mL vial plates

◆ Syringe: 500μL

Refractive Index Detector      Qty:1set

◆ Flow cell type：2 chamber-type

◆ Measuring method：Deflection type

◆ Refractive Index range：1.00 to 1.75

◆ Measuring range：0.25 to 512μRIU

◆ Drift：0.2μRIU/h (Pure water 1mL/min, PURGE OFF)

◆ Linearity range：≥600μRIU

◆ Noise：≤2.5nRIU (Pure water, response : 1.5sec)

◆ Response：0.1 , 0.25 , 0.5 , 1 , 1.5 , 2 , 3 , 6 sec

◆Cell volume：8μL

◆Flow rate：(Usual) 0.2 to 3.0mL/min；(Max.) 10mL/min (solvent: pure water)
