Product  Description

Fluorescent part (B and G bands)

B (Blue light): EX490 DM510 BA515

G (green light): EX545 DM580 BA590

E (ordinary): bright field ordinary transmitted light

HBO high pressure spherical mercury lamp, 100W

Fluorescent dedicated power box

UV protection baffle

Optical Microscope Main Parts

Magnification: 40X-1600X

Viewing head: Infinity compensation trinocular head, 30°inclined, 360° rotatable, interpupillary distance 48-75mm

Eyepiece: Plan P10X/18mm, P16X/15mm,diopter adjustable

Objective: Fluorescence Objective Infinity Plan, 4X, 10X, 40X(Spring), 100X (Spring,Oil)

Nosepiece: Quadruble four holes, inward , steel ball positioning

Stage:  Double Layer Mechanical Moving Stage, can hold two slices,  size 160×142mm, Moving range 76×52mm

Focusing system: Coaxial Coarse and Fine focusing knob, coarse adjustment 22mm, fine adjustment 0.002mm, with hand wheel elastic adjustment, Random limit locking mechanism

Condenser: Abbe condenser, N.A.=1.25, iris diaphragm, concentrator center adjustable

Transmission light source: Halogen lamp 12V/20W, brightness adjustable

Power : external switch power supply,  DC 6V/2A

Carton size: 575x495x375mm, G.weight:19kg
