Product Description

High Pressure Constant Flow Pump  Qty:2 sets

◆ Flow rate range: 0.001-10.000 mL/min, in 0.001 mL increments

◆ Flow accuracy: ≤±0.2% (1.00ml/min, H2O,R.T.,8.5MPa)

◆ Flow precision: RSD≤0.06%  (1.00ml/min, H2O,R.T.,8.5MPa)

◆ Maximum pressure: 45MPa

Low-Pressure Gradient Unit  UV/VIS Detector   Qty:1set

◆ DG3100 vacuum degasser, 4 channel

◆ Composition rang: 0-100%

◆ Composition precision: ≤0.2% RSD

◆ Composition accuracy: ≤±2.0%

Chromatographic Data-processing Workstation   Qty:1set

◆ Internal and external standard calculation methods

◆ Automatically displays, prints, exports and starts other programs after the completion of a measurement.

◆ Comply with the requirements of the 21 CFR Part 11 directive of the FDA

Eclassical 3100 System Kits   Qty:1set

◆ Containing required tubing, fittings, wreches and cables for system.

◆ Valve holder

◆ 7725i manual injector

◆ Supersil ODS2 5μm ID4.6×150mm

◆ Supersil NH2 5μm ID4.6×250mm

◆ Solvent tray

Autosampler

◆ Inject volum range: 0-100 μL (standard)

◆ Precision: RSD <0.3%

◆ linearity: >0.999

◆ Sample residual: <0.01%

◆ Number of sample plates: Two of 60 position 2-mL vial plates

◆ Syringe: 500 μL

ESA Evaporative Light Scattering Detector

◆ Light source: High intensity Halogen lamp

◆ Detector: Photomultiplier (high sensitivity)

◆ Analogue signal output: 0-1 V

◆ Heating time: <10min heat up to 150℃

◆ Temperature range: Evaporation chamber: maximum 150℃, increase by 1℃; Nebulizer: maximum 70℃

◆ Gas flow rate: 1-2 L/min, recommended pressure 1-2 bars

◆ Noise: <1 mVolt (1ml/min)

◆ Nebulizer type: Venture tube
